SVS SB-5000 R|Evolution Subwoofer

About The SVS SB-5000 R|Evolution Subwoofer

With the emergence of new flagship SVS subwoofers, it was only a matter of time before the unprecedented technology made its way to newer models at prices within reach of more people. Now, the 5000 R|Evolution Series brings a level of performance and a user experience that far exceeds anything in its class.

Featuring a sealed cabinet design, SB-5000 R|Evolution delivers pristine musical output with flawless tonal accuracy and unerring control to delight the most discerning audiophiles. Yet, it still wields enough power to pressurise a room and extends down to 17Hz for the most demanding cinematic action scenes.

Effortless low-frequency output and extreme SPLs without a hint of distortion are rendered by a formidable 15” (381mm) driver with dual edge-wound voice coils driven by a 2,000 Watt Continuous, 5,000+ Watts Peak power dual monoblock amplifier.

There are also brains to match the brawn. A 295MHz Analog Devices DSP, the most powerful processor ever deployed in a home audio subwoofer, ensures pinpoint accurate frequency response and optimal performance under any conditions.

SB-5000 R|Evolution demolishes all performance benchmarks for subwoofers in its class. With trickle-down technology from the 17-Ultra R|Evolution Series, named the top subwoofers in the world by nearly every reviewer and industry group, it obliterates expectations, making reference experiences possible for more people than ever.

High-Excursion 5000 R|Evolution Driver: 15-inch glass fibre composite cone with 17.46 kg toroidal ferrite magnet motor assembly render massive low frequency output down to 17Hz with pinpoint accuracy and control.

Dual Edge Wound Voice Coils: Dual voice coil design ensures stable and consistent transfer of motor electro-magnetic energy to the 15-inch cone to maintain precise driver control with maximum efficiency.

Dual Mono Amplifier: Each of the two Class-D mono-block amplifiers with MOSFET output stages drives one of the dual voice coils to double the amount of current being fed to the driver achieving effortless output with lower continuous current demand from a home’s AC circuit.

Switch Mode Power Supply: Time aligns the AC voltage to the AC current while filtering and stabilising incoming voltage to optimise signal quality and audio performance.

295 MHz Analog Devices DSP: The most advanced processor ever used in a consumer subwoofer optimises every aspect of subwoofer output and usability to maintain flawless performance and intuitive control.

SVS Subwoofer Control Smartphone App: Most convenient way to control all DSP functions, including: volume, 6-band parametric equaliser, low pass filter, phase, polarity, room gain, port tuning, system settings, custom presets, and auto room EQ.

Acoustically Tuned Sealed Cabinet Design: Sealed cabinet with double thick MDF and rigid internal bracing creates a resonance-free environment for pitch-perfect accuracy free from resonances and coloration.

Our Review

The SVS SB-5000 R|Evolution is a serious bit of kit for anyone chasing high-performance bass without going overboard on size or price. With a hefty 15-inch driver, twin voice coils, and a powerhouse dual mono amp pushing 2,000 watts continuous (and peaking well past 5,000), it brings muscle and control in equal measure. The sealed cabinet keeps things tight and accurate, whether you're listening to delicate acoustic tracks or watching a blockbuster with deep, rumbling lows. Under the hood, a 295MHz DSP handles the brains side of things, making sure it stays sharp no matter the setup. With App-based controls and smart tuning features, the SB-5000 R|Evolution offers a solid balance of punch, precision, and practicality for both Aussie audiophiles and home theatre buffs alike.

Main Features & Specifications

• Design: Front Firing 15” Sealed Box Powered Subwoofer

Frequency Response / Acoustic Data

• 17Hz to 280Hz +/- 3dB
• Expect 2-3Hz deeper extension in small to mid-size rooms
• Roll-off slope specifically optimized to take maximum advantage of available room gain
• 2 metre ground plane away from reflective structures (quasi-anechoic)

Driver

• All-new proprietary 15” (381 mm) long-throw driver with high-precision tuned overhung motor configuration
• 21 kg Woofer with 17.46 kg motor
• 77.44 mm Xmech precision aligned excursion
• 3” (76 mm) diameter Voice Coil with high current 6-layer bifilar flat edge wound aluminium wire windings
• Dual Voice coil design captures power delivery from dual-mono amplifier outputs into a single voice coil for maximum acoustic output

Amplifier

• Massively powerful 2,000 Watts continuous Class D design with over 5,000 Watts of Peak Power
• High resolution 295Mhz Analog Devices Audio DSP with double precision 56bit filtering, with over 5x the processing power of previous SVS subwoofers
• DSP monitors every function of the amplifier ensuring precisely regulated clean voltage is delivered to and from the switch mode power supply and maximum current is pushed to the driver’s voice coils
• DSP Continuously runs complex power management algorithms and multi-point thermal, voltage, and current monitoring systems to optimize AC voltage delivery to the power supply for continuous peak performance with maximum performance and greatest efficiency

SVS App

• Compatible with Apple iOS, Google Android, and Amazon Fire platforms, the industry leading SVS Subwoofer Control Smartphone app allows convenient and intuitive management of all subwoofer controls
• The Analog Devices DSP supports a comprehensive menu of functions, including volume, fully adjustable low pass filter, phase, polarity, six PEQs, room gain compensation, tuning modes, power management settings, and more
• Includes three convenient memory presets for fast and easy global system adjustments to match listener preferences
• Subwoofer Auto Room Equalization (coming soon) will use your mobile device built-in microphone, or an accessory microphone (coming soon) to measure the acoustic performance of your subwoofer in your room and automatically calculate precision equalization filters to optimize the subwoofer and room combined performance at your listening position.
• Unique bidirectional feedback shows adjustments in real time on both app and subwoofer interface
• Easy-to-follow tutorial provides clear guidance for all functions

General

• Included Accessories: Protective Non-Resonant Extra-Thick ABS Grille Frame with Fabric Mesh Cover, Iso-Elastomer Feet, Extra Heavy-Duty, High Current 1.8m Power Cable, Quick Start Guide
• Removable Power Cable: Upgrade to a Premium Power Cable for better performance
• Available Finishes: Gloss Black and Black Ash
• Dimensions (WxHxD) with Grille: 453 x 465 x 495mm
• Dimensions (WxHxD) without Grille: 453 x 465 x 468mm
• Weight: 46.3 kg
• Manufacturer's Warranty: 5 Years

Note: Features & Specifications Subject To Change Without Notice. E&OE.
