RTI XP-3 Control Processor

RTI XP-3 Control Processor

The RTI XP-3 offers exceptional control and automation performance in a compact form-factor for smaller custom integration projects.

The XP-3 professional control processor delivers powerful automation capabilities perfectly sized for media rooms, bedrooms, conference room control programming, and other focused applications. This compact yet capable processor provides comprehensive custom control programming when paired with RTI remotes, in-wall touch panel controls, or the RTI control app on mobile devices.

Advanced bi-directional communication enables real-time two-way feedback from connected third-party devices including music streamers, cable boxes, lighting control integration systems, security panels, and more. The extensive RTI control system drivers database ensures seamless integration across thousands of compatible devices for any smart home or intelligent office environment.

Programming efficiently with Integration Designer software, the XP-3 enables flexible connectivity via Ethernet, Zigbee, RS-232, IR, and relays. The built-in astronomical clock facilitates sophisticated scheduling for time-based events and automation sequences—perfect for creating "good morning" and "good night" scenes that adjust lighting, climate, and entertainment systems automatically.

Designed for versatility, the XP-3 scales effectively as a standalone solution and works seamlessly with larger RTI processors as a secondary controller in complex multi-room systems. This flexibility makes it ideal for custom technology integrators seeking reliable performance across diverse residential, hospitality, and commercial applications.

2-Way Communication

Convenient and reliable control with status feedback from controlled devices such as on/off or arm/disarm status, dimming value of lights, playlists, available stations.

RS-232 Control

One control port for 3-wire connection with the capability of polling status feedback from controlled devices or systems.

Relay Switching

Two built-in low voltage dry contacts that provide contact closure or switching control for loads up to 5A/30VDC (external power supply required).

Multi-Purpose Input/Output

One Multi-Purpose Input/Output control port that allows for infrared control and connecting voltage sensors or RS-232 communication modules.

Infrared Ports

Two control ports for 2-wire connection to infrared emitters, blasters and repeaters.

Sense Input

Two inputs that sense the voltage state from a voltage sensor to trigger a programmed control command or macro.

10/100 BaseT Ethernet Port

Standard 10/100 BaseT network connection for bidirectional control communication with RTI remotes, touch panels and devices that are controlled over IP network.

Zigbee Connection

Standard wireless Zigbee connection for bidirectional control communication with RTI remotes.

Astronomical Clock

Built-in clock that syncs through an internet connection allows to schedule time-based events to automate all aspects of the installed environment, including climate, lighting, music, and much more.

Why Choose the RTI XP-3?

The RTI XP-3 Control Processor might be compact, but it punches well above its weight when it comes to serious smart-home and AV control. Designed for media rooms, bedrooms, and focused commercial spaces, it’s the kind of behind-the-scenes brain that makes everything work exactly the way it should - lights, music, climate, security and more all snapping into line at the tap of a button. Under the hood there’s a capable 32-bit 533 MHz CPU with plenty of flash memory, while Ethernet with PoE, ZigBee, RS-232, IR, relays and voltage sensing give installers a generous toolkit for integrating just about anything. Bi-directional communication means you’re not just sending commands but getting real-time feedback from compatible devices, and the built-in astronomical clock lets you automate everyday rituals like “good morning” and “good night” scenes with effortless precision. Programmed through RTI’s Integration Designer software and able to run standalone or alongside larger processors in bigger systems, the XP-3 delivers slick, dependable automation in a tidy package that’s far more powerful than its modest footprint suggests.
