Bluesound Professional BCS250 In-Ceiling Speakers

About The Bluesound Professional BCS250 In-Ceiling Speakers

The BCS250 is a premium passive commercial-grade in-ceiling speaker, specifically designed for both low impedance and constant voltage applications in new build or retrofit scenarios. Its discreet design seamlessly blends with any interior design or décor, making it an ideal choice. With a high-performance build, including a UL 2043 plenum rating, the BCS250 is fully certified for commercial installation. Additionally, the optional pendant kit offers the flexibility to suspend the BCS250 from the ceiling at a lower height if there are no suitable mounting options available at the typical height.

The BCS250 are passive in-ceiling speakers that make for a great complement to the B170S Networked Streaming Stereo Amplifier, offering both low impedance and constant voltage options (70/100V). The Low impedance option delivers better audio quality overall, while the constant voltage option allows for daisy chained speaker configurations.

The BCS250 speakers are ideal for a wide range of applications, whether you're retrofitting an existing system or building a new one. Moreover, their user-friendly design makes it effortless to replace or update an existing system for the ultimate installation flexibility. The BCS250 in-ceiling speakers are incredibly discreet, making them ideal for environments where wall space is limited, such as small cafes and shops.

With a slim profile requiring just 5 inches of depth, these speakers can be seamlessly installed, especially in areas where walls are already adorned with various objects.

Our Review

The Bluesound Professional BCS250 is a premium in-ceiling speaker that blends high-performance audio with an impressively discreet design, making it a perfect fit for just about any commercial space. Built for both low impedance and constant voltage (70/100V) setups, it offers flexibility whether you’re after top-tier audio quality or the ability to daisy-chain multiple speakers. With its slim 5-inch profile, UL 2043 plenum rating, and smart features like a snap-fit magnetic grille and quick-connect Phoenix connector, installation is a breeze - whether you’re working on a new build or retrofitting an existing system. Ideal for places where wall space is scarce, like cosy cafés or boutique shops, the BCS250 even has an optional pendant kit for when ceiling height is an issue. Add in its tuned crossover for smooth, uniform sound, and you’ve got a discreet yet powerful audio solution that doesn’t just blend in - it elevates the whole space.

Main Features & Specifications

• Design: Full-Range In-Ceiling Speakers – Sold as a Pair
• Tuned crossover for uniform frequency response over the coverage area
• High dispersion coverage
• Snap-fit magnetic grille
• Long travel dog-ear mount system
• Quick connect Phoenix connector
• Low-saturation and low-loss 70/100V transformers with 8 Ohm bypass
• Slim profile requires only 5 inches of depth
• UL2043, UL1480A certification
• Integration with local network content storage
• Available in White with Black Grille accessory option
• Speakers
  • 1 x 89mm (3.5”) Woofer
  • 1 x 25mm (1”) Tweeter
• Frequency Response: 65Hz-23kHz
• Rated Power: 80 Watts
• Rated Maximum SPL: 105db@i meter average, 110 db peak
• Sensitivity: @1 W, 1m:84db
• Coverage: 150 degrees conical coverage
• Transformer Taps
  • 70 V = 3.5, 7, 15, 30, 8 Ohms
  • 100 V = 7, 15, 30, NC, 8 Ohms
• Input Connector Type: Phoenix connector, Parallel output
• Operating Environment: Designed for indoor use
• Operating Temperature Range: -20 to 50 C
• Included Accessories: Phoenix Connector, White Grille
• Cutout Diameter: 152mm
• Dimensions: 182mm Diameter x 126mm Depth
• Weight: 2.2 kg
• Manufacturer's Warranty: 2 Years

Note: Features & Specifications Subject To Change Without Notice. E&OE.
