Ascendo THE6 Passive On-Wall Speakers

Ascendo THE6 Passive On-Wall Speakers

Quick Info

Compact 6.5" On-Wall Speaker Designed for High Performance in a Small Cabinet

Coaxial Point-Source Technology for Precise, Consistent Sound Dispersion

Versatile Installation for Surround, Ceiling, Background Music, or Optional In-Wall Use

High Output Capability with 90dB Sensitivity and 200W RMS Power Handling

View full details

Ascendo THE6 Passive On-Wall Speakers

We absolutely love what these Ascendo speakers can do. Positioned in the Audio Trends Cinema Two, they are sure to blow you away.

Does quality need to be a matter of size and budget? This new 6.5" addition to the CCM speaker series of ASCENDO was designed by our engineers to offer the highest performance ratio to speaker volume.

Ascendo employ the same proven two way axi-symmetric point source coaxial technology as the larger CCRM speaker series in a more compact packaging. It can serve as a surround and ceiling speaker in larger home theatre systems as well as a music background speaker paired with a subwoofer.

The optional in-wall mounting kit will convert the The6-P into a flexible in-wall speaker.

THE6 Power

The high sensitivity of 90dB/w/m paired with 200W RMS power handling lets you use this speaker with lower power receivers or very high-power amplifiers to achieve record SPL for reference level home theatre projects. Another major advantage of the The6-P is its shallow depth of only 88mm.

Why Choose The Ascendo THE6 Passive On-Wall Speakers?

In mid 2026, it was time to update the cinema sound in our theatre room. We are thrilled at all the Ascendo we have put in that room, and truly believe it is something you need to come down and experience for yourself. We love bang for buck and these Ascendo THE6 On-Walls really hit the spot. Punchy, tight and full range, you don't want to miss out on a product like this. These speakers can also be purchases as an In-Wall model too, perfect if you don't like the look of the On-Wall. But who wouldn't, we think these speakers look awesome.

Main Features & Specifications

  • Design: Speaker Type: 6 ½” time-coherent point-source coaxial
  • Principle: Vented
  • Passive | Active: Passive
  • Woofer: 6 ½” woofer
  • Tweeter: 1” soft dome
  • Recommended ASCENDO Amplifiers: AIA2-1404, AIA4-2404, AIA8-2704, AIA8-6004

Measured Data

  • SPL (Half Space 2pi): Measured Data - 111 dB (Cont.) / 122 dB (Peak)
  • Frequency Range: Measured Data (Without DSP) - 95 Hz - 20 kHz / -3 dB
  • Power Handling: 200 W
  • Efficiency: 90 dB / 1 W/m 2 pi
  • Impedance: 8 Ω
  • Directivity Horizontal x Vertical in deg°: 85° x 85°

Input

  • Input Terminal: 4-conductor Phoenix 12 AWG (3.3 mm²)

Design & Mounting

  • Enclosure: Internally braced MDF
  • Finish: Matte black
  • Mounting: 4 x wall brackets for horizontal and vertical installation, VESA 100 x 100 mounting points, 4 through-holes for direct wall or ceiling mounting

Dimensions & Weight

  • Dimensions (WxHxD) (Without Grille): 260 x 440 x 88mm (With grille: 94)
  • Packing Dimensions (WxHxD): 380 x 570 x 200mm
  • Weight: 5.2 kg
  • Price per speaker
  • Manufacturer’s Warranty: 5 Years

Note: Features & Specifications Subject To Change Without Notice. E&OE.
